MAIN FEATURES

  • Welded, bolted construction body
  • Easy to change screen wires
  • Clack front grooves providing flow in the desired direction
  • Stone-Box anti-wear grooves
  • Two layers of anti-corrosion acrylic
  • 6 mm Hardox-400 bolted lining sheet is used on angled surfaces in front groove and trouser grooves.
  • SPARE PARTS and service books
  • User and maintenance books
    • MODEL (TOP DRIVE) NUMBER OF FLOORS ENGINE OPWER WEIGHT

    CTE-2050 UT

    2-3

    18kW 1100rpm

    16 ton

    CTE-2060 UT

    2-3

    30kW 1100rpm

    19 ton

    CTE-2460 UT

    2-3

    30kW 1100rpm

    22 ton

    TECHNICIAL SPECIFICATIONS

  • A1 quality special crack controlled sheet
  • Wheeled rail front gutter system
  • Washing system independent of sieves on the upper floor
  • Manufacturing of bolted cases made of NPU-100 material
  • Screen reinforcement steel ST-37 material 20 mm welded and bolted connection
  • Heavy-duty main body
  • Power transmission via belt pulley
  • 6 mm swivel front groove
  • Straight bottom discharge chute
  • Side sheet thickness 10 mm ST-37 A1 quality
    • MODEL (MEDIUM DRIVE) NUMBER OF FLOORS ENGINE OPWER WEIGHT

    CTE-1650

    2-3-4

    15kW 1000rpm

    12 ton

    CTE-2050

    2-3

    22kW 1000rpm

    15 ton

    CTE-2060

    2-3

    30kW 1100rpm

    17 ton

    CTE-2460

    2-3-4

    30kW 1100rpm

    19 ton
    A B C D E F G H I J

    2060/4

    8227

    4556

    10329

    5698

    1853

    4218

    4258

    1076

    2000

    2430

    2060/3

    7628

    4556

    9929

    5698

    1853

    4218

    3858

    1076

    2000

    2430

    2060/2

    7144

    4556

    9929

    5698

    1853

    4218

    3858

    1076

    2000

    2430

    2050/2

    6589

    4448

    9225

    5173

    2094

    3238

    3893

    1150

    2000

    2430

    2050/3

    6807

    4448

    9225

    5173

    2094

    3238

    3893

    1150

    2000

    2430

    2050/3

    7097

    4448

    9625

    5173

    2094

    3238

    4293

    1150

    2000

    2430

    1850/2

    6071

    4248

    8925

    4748

    2094

    3238

    3593

    1050

    1800

    2230

    1650/2

    6071

    4048

    8925

    4748

    2094

    3238

    3593

    1050

    1600

    2030

    1650/3

    6607

    4048

    9225

    4748

    2094

    3238

    3893

    1050

    1600

    2030

    1650/4

    6895

    4048

    9225

    4748

    2094

    3238

    3893

    1050

    1600

    2030

    2460/3

    7734

    4954

    9930

    5700

    1853

    4219

    4258

    1175

    2400

    2830

    2460/4

    8228

    4954

    10330

    5700

    1853

    4219

    4258

    1175

    2400

    2830

    2470/4

    8940

    4848

    11675

    6130

    2160

    5232

    4282

    1050

    2400

    2830

    1240/2

    5190

    3163

    6433

    3862

    1480

    2504

    2449

    1175

    1200

    1605
